The control cables are suitable for supervisory electrical equipment, station control circuits, outdoor, suitable installation in dry or wet cable trenches. have moisture, corrosion, and anti-injury characteristics that can be laid in the tunnel or cable trench. Control cables directly transmit electric energy from power distribution points of the power system to power connecting lines of various electric equipment and appliances.
PVC/PVC CVV Control Cable
Conductor: Concentric Stranded copper wire
Cores: 2-30 core
Insulation: PVC Black color
Identification: Printed White number on the surface of Black insulation
Filler: Suitable filler
Binding tape: Suitable tape
Sheath: PVC Black color
Application: For supervisory electrical equipment, station control circuits, outdoor, suitable installation in dry or wet cable trenches.
PVC/PVC CVV-S Screen Control Cable
Conductor: Concentric Stranded copper wire
Core: 2-15 cores
Insulation: PVC Black color
Identification: Printed White number on the surface of Black insulation
Filler: Suitable filler
Binding tape: Suitable tape
Inner sheath: PVC Black color
Shield: Annealed copper tape
Binding tape: Suitable tape
Outer Sheath: PVC Black color
Application: For supervisory electrical equipment, station control circuits, outdoor, suitable installation in dry or wet cable trenches.
CVV-SWA Armoured Control Cable
Conductor: Concentric Stranded annealed copper wire
Insulation: PVC Black color
Core: 2-30 Core
Identification: Printed White number on the surface of Black insulation
Filler: Suitable filler
Binding tape: Suitable tape
Inner sheath: PVC Black color
Armour: Galvanized steel wire
Binding tape: Suitable tape
Outer Sheath: PVC Black color
Application: For use in duct, tray and fo
DIN VDE Srandard JZ-500 PVC Control Cable
Voltage: 300/500V
Conductor: Concentric Stranded annealed copper wire
Insulation: PVC Black color
Core: 2-30 Core
Temperature range
flexing -15 °C up to +80 °C/fixed installation -40 °C up to +80 °C
Application: in mechanical and plant engineering, machine tools, production lines and conveyor belts.
IEC 60502 Standard CVV-S Control Cable Parameter
| No. of | cross-sectional area | No.& dia. | Thickness of | Thickness of | Overall diameter | Cable | |
| of wires | insulation | inner sheath | outer sheath | (Approx.) | weight (Approx.) | ||
| core | mm2 | No./mm | mm | mm | mm | mm | kg/km |
| 7 | 0.5 | 7/0.30 | 0.8 | 1 | 1.8 | 15.5 | 275 |
| 0.75 | 7/0.37 | 0.8 | 1 | 1.8 | 16 | 315 | |
| 1 | 7/0.40 | 0.8 | 1 | 1.8 | 16.5 | 330 | |
| 1.5 | 7/0.50 | 0.8 | 1 | 1.8 | 17.5 | 395 | |
| 2.5 | 7/0.67 | 0.8 | 1 | 1.8 | 19 | 520 | |
| 4 | 7/0.85 | 1 | 1 | 1.8 | 22 | 730 | |
| 6 | 7/1.04 | 1 | 1 | 1.8 | 24 | 930 | |
IEC 60502 CVV-SWA Armoured Control Cable Parameter
| No.of | cross-sectional area | No.&dia | Thickness of | Diameter of | Thickness of | Overall diameter | Cable weight | |
| .of wires | insulation | inner sheath | steel wire armor | outer sheath | (Approx.) | (Approx.) | ||
| core | mm2 | No./mm | mm | mm | mm | mm | mm | kg/km |
| 8 | 0.5 | 7/0.30 | 0.8 | 1.2 | 1.25 | 1.8 | 20 | 625 |
| 0.75 | 7/0.37 | 0.8 | 1.2 | 1.25 | 1.8 | 20.5 | 680 | |
| 1 | 7/0.40 | 0.8 | 1.2 | 1.25 | 1.8 | 21 | 710 | |
| 1.5 | 7/0.50 | 0.8 | 1.2 | 1.25 | 1.8 | 22 | 810 | |
| 2.5 | 7/0.67 | 0.8 | 1.2 | 1.25 | 1.8 | 24 | 995 | |
| 4 | 7/0.85 | 1 | 1.2 | 1.6 | 1.8 | 28 | 1470 | |
| 6 | 7/1.04 | 1 | 1.2 | 1.6 | 1.8 | 30 | 1770 | |
